GES9-3 service outlet with handle clamp, for 3 cover plates APMT5
Trench Part No. GES9-3 UME 7011
|OBO Item No. 7405097
|EAN 4012196490608
Trench Part No.
GES9-3 UME 7011
OBO Item No.
7405097
Floor covering thickness
5 mm
Opening mechanism
Handle
Colour
Iron grey; RAL 7011
Smallest selling unit: 1 piece
1piece
piece
Description
Service outlet with metal installation frame for mounting of 3 cover plates of shape APMT5, for use in UGD and UDS underfloor boxes.
Universal fastening brackets adjustable to floor thicknesses up to 65 mm.
Carpet protection frame, hinged lid and cord outlet made of PC/ABS.
Floor covering recess in the hinged cover pre-adjusted to 5 mm, if necessary adjustable to 10 mm.
Universal fastening brackets adjustable to floor thicknesses up to 65 mm.
Carpet protection frame, hinged lid and cord outlet made of PC/ABS.
Floor covering recess in the hinged cover pre-adjusted to 5 mm, if necessary adjustable to 10 mm.
Technical data
Dimensions
| Height | 70 mm |
|---|
Technical data
| Floor covering thickness | 5 mm |
|---|---|
| Suitable for screed-covered underfloor ducts | yes |
| Suitable for screed-flush closed underfloor ducts | no |
| Number of installable devices | 6 |
| Seal installation option | no |
| Length of installation dimensions | 244 mm |
| Wide installation dimensions | 244 mm |
| Length of external dimensions | 264 mm |
| Wide external dimensions | 264 mm |
| Suitable for cavity floor installation | yes |
| Suitable for raised floor installation | yes |
| Floor care | Dry |
| Frame version | Carpet protection frame |
| Number of mounting boxes | 3 |
| Suitable for wet care | no |
| Cable outlet version | Swivellable cord outlet |
| Protection rating IK code | IK08 |
| Protection rating (IP) when used | IP20 |
| Protection rating (IP) when unused | IP40 |
| Version for | Square |
| Opening mechanism | Handle |
| Clamping range D, max. | 76 mm |
| Clamping range D, min. | 8 mm |
| Dimension | 264x264x70 |
| Material | Polyamide |
| Colour | Iron grey; RAL 7011 |
| Floor covering thickness max. | 10 mm |
Environmental Data
7,6241 kg CO2e / 1 PieceCO2 Footprint (GWP) Cradle-to-Gate
| CO2 Footprint (GWP) Cradle-to-Gate | 7,6241 kg CO2e / 1 Piece |
|---|
